Characteristic Impedence 10015? at 1 ~ 550MHz
Conductor Construction Solid Bare Copper. Conductor Resistance 93.8?/km/20 DegreeC max. Conductor Size 23AWG x 4 pairs
Dielectric Strength AC 1.5kV/min
Flame Retardant Test CM. Insulation Material FEP. Jacket Material FRPVC
Mutual Capacitance 56pF/m max. Propagation Delay 536nS/100m max at 550MHz. Spark Test 2.5kV
Standards Compliance ISO/IEC 11801; TIA/EIA-568-B.2-1
Jacket Diameter 6.000.20mm
Structural Return Loss 8.6dB min at 550MHz
